4K60 Video Wall Controller with 9 HDMI Outputs for Seamless Switching Multi-Screen Display

Name: 4K60 Video Wall Controller with 9 HDMI Outputs for Seamless Switching MultiScreen Display
Brand: Bitvisus
Price: 1 USD

China 4K60 Video Wall Controller with 9 HDMI Outputs for Seamless Switching Multi-Screen Display wholesale

Place of Origin : Guangdong, China

MOQ : 1

Price : Contact us

Brand Name : Bitvisus

Model Number : BIT-VWC-U1-809MV

Certification : CE,HDMI,HDCP,RoHS,FCC

Payment Terms : T/T,PayPal

Supply Ability : 1000

Delivery Time : 5-8 days

Packaging Details : 540mmX400mmX165mm

Input Interface : 2 HDMI2.0/DP1.2, 2 HDMI2.0, 4 HDMI1.3

Maximum Input Frequency : 600MHz

Output Interface : 9 HDMI 1.3, 1 HDMI 2.0

Maximum Output Frequency : 154MHz

Output Resolution : 1920X1080P60,1920X1200P60

Control Method : RS232, network port web

Power Supply : 12V5A

Packaging Dimensions : 540mmX400mmX165mm

Input Resolution : IN1-4: 3840×2160P60, IN5-8: 1920×1080P60

Color Depth : 8bit

Input Color Format : RGB444, YUV444, YUV422, YUV420

Power Consumption : 40W

Operating Temperature : 0～50ºC

Product Dimensions : 483mm×200mm×60mm

Product Weight : 2.8KG

Contact Now

Product Description

1、Support 8 inputs, including 4-channels 4K60 (2-channels HDM/DP option),4-channels 1080P60, support 9-channels 1080P60 output. Multi-input andmulti-output to meet a variety of application requirements;Support 1 channels HDMl local display back; 2、Support remote control, RS232, network WEB control, you can log in WEB forcontrol on Windows computer, Apple computer, Pad, mobile phone and otherdevices, easy and flexible to realize the control and selection of input and output ofthe device; 3、Support multi-screen display, you can combine a signal into one screen outputdisplay, you can also display different contents in multiple screens; 4、Support seamless switching of` input signals without black screen or flashingscreen. 5、Built-in output signal enhancement to ensure signal stability and clarity duringlong-distance transmission. 6、Adopt imported industrial-grade chip, 28nm process is stable and reliable, withgood heat dissipation design and protection measures to ensure stable operation fora long time.

4K60 Video Wall Controller with 9 HDMI Outputs for Seamless Switching Multi-Screen Display

Specification

Produduct Name	BIT-VWC-U1-809MV
Input Maximumum PixelClock Frequency	600MHz
Input Interfaface	ININ1-2：2×HDMI 2.0、2×DP 1.2ININ3-4：2×HDMI 2.0ININ5-8：4×HDMI 1.3
Input Resolution	ININ1-4：3840×2160P60ININ5-8：1920×1080P60
Color depth	8bit
Input color foformrmat	RGB444、YUV444、YUV422、YUV420
Outptput Interfaface	9×HDMI 1.3，1×HDMI 2.0
Outptput Maximumum PixelClock Frequency	154MHz
Outptput resolution	Remote control, RS232, Network rk interfaface Web
Audio	3.5MM Audio Split
Power supupply	12V5A
Power Consumption	40W
Storage/OperatingTemperature	-10～50ºC/0～50ºC
Produduct Dimensions	L×W×H：483mm×200mm×60mm
Produduct Weight	2.8KG
Accessory List	1×12V5A power adapapter, 1×Phoenix termrminal, 1×Bluenetwork rk cabable, 1×IR infrfrared head, 1×Remote control
